Getting Started (continued) Section Two
COMPONENTS
The LVU500 series is offered in two different models with 4-20 mA output and relay control. Depending on the
model purchased, you may or may not have been shipped all the components shown below. All G threaded
process mounts require a FKM gasket for installation and operation of LVU500 series.
P/N
Max.
Range
Dead
Band
Thread Fob Output Configuration
LVU503-B
9.8’
(3m)
4”
(10cm)
2” NPT
Not Included
4-20mA
&
4 SPST
Relays
LVCN414-SW
only
LVU503 Included
LVU503-G-B
2” G
Not Included
LVU503-G Included
LVU501-B
4.9’
(1.5m)
1.5”
(3.81cm)
2” NPT
Not Included
LVU501 Included
LVU501-G-B
2” G
Not Included
LVU501-G Included
 FKM Gasket (G threaded version only)
o Part #210138
 Fob (LVU501, LVU501-G, LVU503 & LVU503-G version only)
o Part #LVU500-USB
 Quick Start Guide
