omi ED24-SR - E) Dryer Dimensions; E) Dimensions du Sécheur

Cod. 710.0138.62.00 Rev00 – 03.2016 26 - 30
E) DRYER DIMENSIONS - DIMENSIONS DU SECHEUR
Models ED18 to ED25-SR
A B C D E F G H
mm
305 360 408 51 40 50 332 24
3/8"
NPT
3/8"
NPT
Ø
6mm
115/1/60
V/ph/Hz
inches
12" 14"
3/16
16"
1/16
2" 1"
9/16
2" 13"
1/16
15/16"
Power supply Alimentation Air flow Circulation de l'air
Models ED54 to ED180
A B C D E F G H L
ED54
to
ED72
mm 390 432 441 100 85 65 45 65 12
1/2"
NPT
1/2"
NPT
Ø
6mm
115/1/60
V/ph/Hz
inches
15"
3/8
17" 17"
3/8
3"
15/16
3"
3/8
2"
9/16
1"
3/4
2"
9/16
7/16"
ED108
to
ED180
mm 420 516 551 100 85 80 44 63 12
3/4"
NPT
3/4"
NPT
Ø
6mm
115/1/60
V/ph/Hz
inches
16"
9/16
20"
5/16
21"
11/16
3"
15/16
3"
9/16
3"
3/16
1"
3/4
2"
1/2
7/16"
