7.1 Ordering information
Table 7-1:
Ordering information
7.2 Diagrams
Refer also to table 3-1 “Accuracy data” on page 10.
Figure 7-1:
Maximum amplitude error
at measurement range
100 mV/A for
measurement currents of
0-10 A (AC/DC)
The given accuracy data refer to the measured value. An additional
measurement error of +/- 5 mA must be taken into account.
Order description Order number
C-Probe 1
AC/DC current clamp
Supplied with 9 V battery and user manual
VEHZ 4000
Maximaler
A
mplitudenfehler im Meßbereich 100 m
V
/
A(0-10A)
-8
-7
-6
-5
-4
-3
-2
-1
0
1
2
1 10 100 1000 10000
Frequency
/
Hz
Max. error / %
DC
+1.5%/-1.5% +1%/-1% +1.5%/-1.5%
+1.5%/-7%
Maximum amplitude error at measurement range 100 mV/A (0-10 A)
