CP SB1 User Manual
16
Figure 1-2 Front panel
AC Input
DC Input
V1 AC Output
V DC Output
Serial
connection
Transformer High
Voltage
Tap Changer
Up
Down
Equipotential
ground
terminal
Transformer Low
Voltage
LEDs
Read the
manual
