Technical Data
4 Technical Data
4.1 Specifications
4.2 Environmental Conditions
4.2.1 Climate
Table 4-1 Specifications
Characteristic Rating
AC Input / V1 AC Output max. 300 Veff
DC Input max. 6 A DC
Transformer High and Low
Voltage connections
max. 300 Veff between all connectors and
ground
Tap Changer Two potential-free contacts, short circuit-
protected; 0-240 V AC (only AC permitted);
Overvoltage Category II;
Resistance per contact = max. 4 Ω
I continuous = 0.9 A rms
Supply Via serial interface from CPC 100 (+15 V)
Overvoltage protection to case
with surge arrestors
All connections to Tranformer High and Low
voltage side; AC/DC Input; V1 AC / V DC
Output
Table 4-2 Climate
Climate
Operating temperature –10 … +55 °C (+14 … 131 °F)
Storage and transportation –20 … +70 °C (–4 … 158 °F)
Max. altitude 2000 m
Humidity 5 … 95% relative humidity; no condensation
Tested according to IEC 68-2-78
