17
Hardware Information
1.4 CP SB1 Accessories
The following accesories are delivered with the CP SB1 tranformer switch box:
Table 1-1 CP SB1 Accessories
Accessories Description
1x Transport case To transport the entire
equipment
Coax. cables
15 m/2.5 mm
2
3x red, 3x blue, 2x
green, 2x yellow
supplied in cable drums
Connection from the
CP SB1 to the
transformer via Kelvin
clamps and the tap
changer via flexible
terminal adapter
1x Grounding cable Connection from the
CP SB1’s equipotential
ground terminal to the
substation ground
Banana cables
2m
4x red and 4x black
Connection from the
CPC 100 to the
CP SB1’s DC input, V1
AC output and V DC
output
