CP SB1 User Manual
54
4.2.2 Shock and Vibration
4.2.3 Mechanical Data
4.2.4 Cleaning
To clean the CP SB1, use a cloth dampened with isopropanol alcohol or water.
Prior to cleaning, always disconnect the CP SB1.
Table 4-3 Shock and Vibration
Dynamics
Vibration Tested according to IEC 60068-2-6;
frequency range 10 … 150 Hz; acceleration
2 g continuous (20 m/s
2
); 20 cycles per axis
Shock Tested according to IEC 60068-2-27
(operating mode); 15 g / 11 ms, half-sinusoid,
3 shocks in each axis
Table 4-4 Mechanical Data
Weight, Dimensions and Protection
Weight CP SB1
Weight filled transport case
3.5 kg (7.7 lbs)
28.5 kg (62.7 lb)
Dimensions W x H x D CP SB1
Dimensions transport case
357 x 235 x 111 mm
(14.7 x 9.2 x 4.4")
700 x 450 x 500 mm
(27.6 x 17.7 x 19.7")
Housing and transport case IP20 according to EN 60529
