Omicron CP SB1 User Manual

29
Application
Dzn2 A U-(V+W) /
H1-(H2+H3)
n-v / X0-X2 1.5
BV-(U+W) /
H2-(H1+H3)
n-w / X0-X3
CW-(U+V) /
H3-(H1+H2)
n-u / X0-X1
Dz2 A U-V / H1-H2 w-v / X3-X2 1
B V-W / H2-H3 u-w / X1-X3
C W-U / H3-H1 v-u / X2-X1
Dzn4 A U-(V+W) /
H1-(H2+H3)
w-n / X3-X0 1.5
BV-(U+W) /
H2-(H1+H3)
u-n / X1-X0
CW-(U+V) /
H3-(H1+H2)
v-n / X2-X0
Dz4 A U-V / H1-H2 w-u / X3-X1 1
B V-W / H2-H3 u-v / X1-X2
C W-U / H3-H1 v-w / X2-X3
Table 3-1 Different Vector Groups (continued)
IEC
60076
vec-
tor
group
Winding connection Mea-
sure-
ment
Trans-
former
high-
voltage side
Trans-
former
low-voltage
side
Mea-
sured
turn
ratio
HV / H LV /X
U/H1
W/H3
V/H2
u/X1
w/X3
v/X2
U/H1
W/H3
V/H2
u/X1
w/X3
v/X2
U/H1
W/H3
V/H2
u/X1
w/X3
v/X2
U/H1
W/H3
V/H2
u/X1
w/X3
v/X2
