CP SB1 User Manual
72
In the Figures 5-14 and 5-15, an analysis of a transformer with shorted turns in
the low-voltage winding (phase A) is shown.
Figure 5-14 Ratio magnitude = f(f)
Figure 5-15 Ratio phase angle = f(f)
Ratio magnitude
Ratio magnitude
Phase A
Phase B
Phase
C
Frequency
Phase A
Phase B
Phase C
Ratio angle
Frequency
Ratio angle
