7．Connection Procedure
7.4.3. Connecting Online and Transferring the Project Data
Connect online with the Sysmac Studio and transfer the project data to the Controller.
Always confirm safety at the destination node before you transfer a user
program, configuration data, setup data, device variables, or values in memory
used for CJ-series Units from the Sysmac Studio.
The devices or machines may perform unexpected operation regardless of the
operating mode of the CPU Unit.
Always confirm safety before you reset the Controller or any components.
1
Select Change Device from the
Controller Menu.
2
The Change Device Dialog Box
is displayed.
Confirm that Device and Version
are set.
*If the settings are incorrect,
select the setting items from the
pull-down list.
Click the OK Button.
3
If the setting is changed in step
2, the Build Dialog Box is
displayed. Click the Yes Button.
24
To Next Page
