7 - 3
7 Precautions for Use of Parameters for DriveProgramming
DriveProgramming User’s Manual (I622-E1)
7-1 Inverter Parameters Affected by Setting Order
7
bA203 Lower frequency limit, 2nd motor Lower frequency limit, 2nd motor [bA203]
Async.Motor Maximum frequency setting, 2nd-
motor [Hb205]
Lower frequency limit, 2nd motor [bA203]
Sync.Maximum frequency setting, 2nd-motor
[Hd205]
bC120 Free electronic thermal frequency-1, 1st-
motor
0.00 to Free electronic thermal frequency-2, 1st-
motor [bC122](Hz)
bC122 Free electronic thermal frequency-2, 1st-
motor
Free electronic thermal frequency-1, 1st-motor
[bC120] to Free electronic thermal frequency-3, 1st-
motor [bC124](Hz)
bC124 Free electronic thermal frequency-3, 1st-
motor
Free electronic thermal frequency-2, 1st-motor
[bC122] to 590.00(Hz)
bC220 Free electronic thermal frequency-1, 2nd-
motor
0.00 to Free electronic thermal frequency-2, 2nd-
motor [bC222](Hz)
bC222 Free electronic thermal frequency-2, 2nd-
motor
Free electronic thermal frequency-1, 2nd-motor
[bC220] to Free electronic thermal frequency-3,
2nd-motor [bC224](Hz)
bC224 Free electronic thermal frequency-3, 2nd-
motor
Free electronic thermal frequency-2, 2nd-motor
[bC222] to 590.00(Hz)
bA-31 Decel-stop at power failure starting voltage 200Vclass: 0 to 410.0(V)
400Vclass: 0 to 820.0(V)
Decel-stop at power failure starting voltage [bA-31]
Decel-stop at power failure control target level
[bA-32]
bA-32 Decel-stop at power failure control target level 200Vclass: 0 to 410.0(V)
400Vclass: 0 to 820.0(V)
Decel-stop at power failure starting voltage [bA-31]
Decel-stop at power failure control target level
[bA-32]
Cb-05 Start rate of Terminal [Ai1] 0.0 to End rate of Terminal [Ai1] [Cb-06](%)
Cb-06 End rate of Terminal [Ai1] Start rate of Terminal [Ai1] [Cb-05] to 100.0(%)
Cb-15 Start rate of Terminal [Ai2] 0.0 to End rate of Terminal [Ai2] [Cb-16](%)
Cb-16 End rate of Terminal [Ai2] Start rate of Terminal [Ai2] [Cb-15] to 100.0(%)
Cb-25 Start rate of Terminal [Ai3] -100.0 to End rate of Terminal [Ai3] [Cb-26](%)
Cb-26 End rate of Terminal [Ai3] Start rate of Terminal [Ai3] [Cb-25] to 100.0(%)
CE-40 Window comparator for [Ai1] higher level Set an upper limit level.
Setting range: 0. to 100.
Lower limit: Window comparator for [Ai1] lower level
[CE-41] + Window comparator for [Ai1] hysteresis
width [CE-42] × 2
CE-41 Window comparator for [Ai1] lower level Set a lower limit level.
Setting range: 0. to 100.
Upper limit: Window comparator for [Ai1] higher
level [CE-40] - Window comparator for [Ai1] hyster-
esis width [CE-42] × 2
CE-42 Window comparator for [Ai1] hysteresis width Set a hysteresis width for the upper and lower limit
levels.
Setting range: 0. to 10.
Upper limit: (Window comparator for [Ai1] higher
level [CE-40] - Window comparator for [Ai1] lower
level [CE-41])/2
Parameter
No.
Description Data
