7 Precautions for Use of Parameters for DriveProgramming
7 - 4
DriveProgramming User’s Manual (I622-E1)
CE-43 Window comparator for [Ai2] higher level Set an upper limit level.
Setting range: 0. to 100.
Lower limit: Window comparator for [Ai2] lower level
[CE-44] + Window comparator for [Ai2] hysteresis
width [CE-45] × 2
CE-44 Window comparator for [Ai2] lower level Set a lower limit level.
Setting range: 0. to 100.
Upper limit: Window comparator for [Ai2] higher
level [CE-43] - Window comparator for [Ai2] hyster-
esis width [CE-45] × 2
CE-45 Window comparator for [Ai2] hysteresis width Set a hysteresis width for the upper and lower limit
levels.
Setting range: 0. to 10.
Upper limit: (Window comparator for [Ai2] higher
level [CE-43] - Window comparator for [Ai2] lower
level [CE-44])/2
CE-46 Window comparator for [Ai3] higher level Set an upper limit level.
Setting range: 0. to 100.
Lower limit: Window comparator for [Ai3] lower level
[CE-48] + Window comparator for [Ai3] hysteresis
width [CE-47] × 2
CE-47 Window comparator for [Ai3] lower level Set a lower limit level.
Setting range: 0. to 100.
Upper limit: Window comparator for [Ai3] higher
level [CE-46] - Window comparator for [Ai3] hyster-
esis width [CE-48] × 2
CE-48 Window comparator for [Ai3] hysteresis width Set a hysteresis width for the upper and lower limit
levels.
Setting range: 0. to 10.
Upper limit: (Window comparator for [Ai3] higher
level [CE-46] - Window comparator for [Ai3] lower
level [CE-47])/2
Hb150 Free-V/f frequency 1 setting, 1st-motor 0.00 to Free-V/f frequency 2 setting, 1st-motor
[Hb152](Hz)
Hb152 Free-V/f frequency 2 setting, 1st-motor Free-V/f frequency 1 setting, 1st-motor [Hb150] to
Free-V/f frequency 3 setting, 1st-motor [Hb154](Hz)
Hb154 Free-V/f frequency 3 setting, 1st-motor Free-V/f frequency 2 setting, 1st-motor to
Free-V/f frequency 4 setting, 1st-motor [Hb156](Hz)
Hb156 Free-V/f frequency 4 setting, 1st-motor Free-V/f frequency 3 setting, 1st-motor [Hb154] to
Free-V/f frequency 5 setting, 1st-motor [Hb158](Hz)
Hb158 Free-V/f frequency 5 setting, 1st-motor Free-V/f frequency 4 setting, 1st-motor [Hb156] to
Free-V/f frequency 6 setting, 1st-motor [Hb160](Hz)
Hb160 Free-V/f frequency 6 setting, 1st-motor Free-V/f frequency 5 setting, 1st-motor to
Free-V/f frequency 7 setting, 1st-motor [Hb162](Hz)
Hb162 Free-V/f frequency 7 setting, 1st-motor Free-V/f frequency 6 setting, 1st-motor to
Async.Motor Base frequency setting, 1st-motor
[Hb104](Hz)
Hb250 Free-V/f frequency 1 setting, 2nd-motor 0.00 to Free-V/f frequency 2 setting, 2nd-motor
[Hb252](Hz)
Hb252 Free-V/f frequency 2 setting, 2nd-motor Free-V/f frequency 1 setting, 2nd-motor to
Free-V/f frequency 3 setting, 2nd-motor
[Hb254](Hz)
Parameter
No.
Description Data
