3 - 7
3 Operation Procedure for DriveProgramming
DriveProgramming User’s Manual (I622-E1)
3-2 Parameters Related to DriveProgramming
3
The following functions are provided to monitor the status of the DriveProgramming.
Monitor Function of DriveProgramming
Parameter
No.
Function name Data Description
db-01 Program download monitor 00: Without a program
01: With a program
00: (Program is not downloaded.)
01: (Program is downloaded.)
db-02 Program No. monitor 0 to 9999 Transferred program No. is displayed.
db-03 to
db-07
Program counter 1 to 1024 While each task (Task 1 to Task 5) is exe-
cuted, line number is monitored.
db-08 User monitor 0 -2147483647 to
2147483647
Data output to Umon (00) to Umon (04) in a
program is monitored.
db-08Umon (00)
db-10Umon (01)
db-12Umon (02)
db-14Umon (03)
db-16Umon (04)
db-10 User monitor 1 -2147483647 to
2147483647
db-12 User monitor 2 -2147483647 to
2147483647
db-14 User monitor 3 -2147483647 to
2147483647
db-16 User monitor 4 -2147483647 to
2147483647
db-18 Analog output monitor YA0 0 to 10000 Data output to YA (00) to YA (02) in a program
is monitored.
YA0 db-18YA (00)
YA1 db-19YA (01)
YA2 db-20YA (02)
db-19 Analog output monitor YA1 0 to 10000
db-20 Analog output monitor YA2 0 to 10000
