B7AP
B7AP
108
Note: 1. The maximum I/O points refers the maximum I/O points handled simultaneously by the B7A Input and Output Units. Figures in
parentheses
indicate the maximum I/O points handled simultaneously by the B7A Input and Output Units each connected with an
independent
power supply
. Refer to
Power Supplies
on page
110.
2.
The maximum I/O points are the same as the maximum input points of the B7A Input Unit connected to the B7AP-M1.
3. PLCs
and three-wire sensors can be connected only
if the B7A Input and Output Units are each connected with an independent
power supply
. Refer to
Power Supplies
on page
110.
Specifications
Communications Specifications
Communications
method
Unidirectional, time-division multiplex
T
ransmission distance (couplers)
8±
1.5 mm
T
ransmission distance (B7A)
100 m max. (see note 1)
I/O delay time
Typical:
19.2 ms; 31 ms max.
Minimum coupler interfacing time
0.3 s (see note 2)
Minimum distance between Power
Couplers mounted in parallel
60 mm
Note: 1.
The value is for the case where a power supply is provided only for the B7AP-S1.
2. Minimum coupler interfacing time is the minimum time required for signal and power transmission between the B7AP-S1 and
B7AP-M1
Power Couplers.
Characteristics
Item B7AP-S1 B7AP-M1
Power
supply voltage
24 VDC ±10% ---
Current consumption
300 mA
---
Insulation resistance
100 M
Ω
min. (at 500 VDC) between each lead wire and external parts
Dielectric strength
1,000 V
AC, 50/60 Hz for 1 min between each lead wire and external parts
Noise immunity
Noise level: 1.5 kV
; pulse width: 100 ns to 1
µ
s (on transmission line due to coupling)
V
ibration resistance
10 to 55 Hz, 1.5-mm double amplitude
Shock resistance
500 m/s
2
Ambient temperature
Operating:
–10 to 55
°
C (with no icing or condensation)
Storage:
–25 to 65
°
C (with no icing or condensation)
Ambient humidity
Operating:
35% to 95% (with no condensation)
Cable pulling strength
49 N
Nut tightening strength
39 N
S
m
Enclosure rating
IEC IP67
Maximum cable length
2 m
Weight
Approx. 300 g Approx. 230 g
EMC
Radiated Emissions:
EN55022 class A
Radiated Immunity:
prEN50082-2
Electrostatic Discharge: prEN50082-2
Burst Transients: prEN50082-2
Approved standards
UL508
Conforms to EN50081-2, EN50082-2
Moving Unit Specifications
Output
voltage
12 VDC ±10%
Output current
38 mA
Note: Use
the Moving Unit so that the total current consumption of all input devices is 38 mA max. if power is supplied to the input devices
through
the Moving Unit.
