Omron B7A - 10-Point Terminal Models

B7A
B7A
3
10-point Terminal Models
Note: The 10-point model has a normal I/O delay time of 19.2 m (typical); 10-point models with short I/O delay time are not available.
The transmission signals of the 16-point PLC connector model are not compatible with those of the 10-point model. Therefore
16-point
PLC connector models and 10-point models cannot be used in combination.
B7A
B7A
B7AC
B7A
B7A
F
A connector model (10 points)
Modular model (10 points) Modular model (10 points)
Screw terminal model (10 points) Screw terminal model (10 points)
Input (Transmission) Output (Reception)
DRT1-B7AC
DeviceNet
model
