CS1 and C200HX/C200HG/C200HE/C200HS/C200H B7A Interface Units
Note: Use
combinations of B7A Interface Units and B7A LInk T
erminals with the same I/O delay time. The I/O delay time (high speed:
typically 3 ms; normal speed: typically 19.2 ms) can be switched for B7A Interface Units (except for C200H-B7AI1 and
C200H-B7AO1) and 32-point B7A screw terminal models using a selection switch. Set the same I/O delay time for connected
Units.
16-point Input (Transmission)
Models
CS1/C200H Series
16-point Output
(Reception) Models
B7AS
C200H-B7A22
(32
input and 32 output points)
C200H-B7A21
(16 input and 16 output points)
C200H-B7A12
(32 inputs)
C200H-B7AI1 (16 inputs)
C200H-B7A02 (32 outputs)
C200H-B7AO1 (16 outputs)
Screw
terminal model
(32 points)
Screw terminal model
(16 output points)
Modular model (16 points)
B7A
Hybrid IC model (16 points)
B7AH
PLC connector model
(16 points)
B7A
PLC connector model
(32 points)
B7A
Input/output model
Input model
Output model
Note: Two
16-type models can be used to connect
to
32-point models.
Screw terminal model
(16 points)
B7A
B7AS
Relay-mounted screw terminal
model (16 points)
G70D-R6jj1-B7A
Note: Only
the
normal I/O delay
time
(typically 19.2 ms) is
available.
Modular
model (16 points)
B7A
Hybrid IC model (16 points)
B7AH
PLC connector model
(16 points)
B7A
PLC connector model
(32 points)
B7A
B7A
B7AS
