Operation
Note: The
B7AM transmits input signals from SIG1 (input terminal) to SIG2 (output terminal). If an error results while
the
B7AM is transmitting input signals, an error signal is output from the output side only
.
ERR
ERR
Limit switch, proximity sensor, or photoelectric sensor
Sixteen-point output
Sixteen-point input
Indicator or valve
Indicator or valve
Limit switch, proximity sensor, or photoelectric sensor
Sixteen-point input
Sixteen-point output
Dimensions
Note: All
units are in millimeters unless otherwise indicated.
