B7AM-8j
B7AM-8j
63
Operation
Note: The B7AM transmits input signals from SIG1 (input terminal) to SIG2 (output terminal). If an error results while
the B7AM is transmitting input signals, an error signal is output from the output side only .
ERR
ERR
Limit switch, proximity sensor, or photoelectric sensor
Eight-point output
Eight-point input
Indicator or valve
Indicator or valve
Limit switch, proximity sensor, or photoelectric sensor
Eight-point input
Eight-point output
Dimensions
Note: All units are in millimeters unless otherwise indicated.
114.5
113.5
105
45
29
8
4
37
(16.24)
35.3
32
35
Two, 4.5 dia.
4.9
4
4.25
