B7AC
B7AC
73
Suitable Connectors
Be
sure to put the XS2Z-12 W
aterproof Cover or XS2Z-15 Dust Cover on any unused connector
.
For Input (Connector No. 0 to 9)
XS2G-D4jj Assembling connector (crimp-style/solder-type/screw-type) plug
XS2H-D421-jjj
Cable with a connector (plug) at one end
XS2W-D42j-jjj
Cable with connectors at both ends (socket and plug)
For Transmission Path and Power Supply Line (Connector No. P)
XS2C-D4jj Assembling connector (crimp-style/solder-type/screw-type) socket
XS2F-D42j-j80
Cable with a connector at one end (socket)
Specifications
Characteristics
General
Communications
method
Unidirectional, time-division multiplex
T
ransmission distance
100 m max.
I/O delay time
T
ypical: 19.2 ms; 31 ms max.
Minimum input time (see note)
16 ms
Operating voltage range
24 VDC (21.6 to 26.4 VDC)
Insulation resistance
100 M
Ω
min. (500 V) between each terminal and external parts
Dielectric strength
1,000 V
AC, 50/60 Hz for 1 min between each terminal and external parts
Noise immunity
Noise level: 1.5 kV
; pulse width: 100 ns to 1
µ
s (on transmission line due to coupling)
V
ibration resistance
10 to 55 Hz, 1.5-mm double amplitude
Shock resistance
300 m/s
2
Ambient temperature
Operating:
–10 to 55
°
C (with no icing)
Storage:
–25 to 65
°
C (with no icing)
Ambient humidity
Operating: 35% to 85% (with no condensation)
Enclosure rating
IEC IP67
Weight
Approx. 420 g
Note:
The minimum input time is required for the B7AC to read an input signal.
Enclosure Rating
•
Do not continuously impose external force on the joint of the contact block and cover
, otherwise IP67 may not be maintained.
•
IP67 does not ensure that the B7AC is perfectly watertight. Do not use the B7AC underwater
.
•
The case of the B7AC is made of plastic resin. Do not put heavy objects on it.
B7AC-T10A1/B7AC-T10A1-A Input
Compatible
inputs
Switches, two-wire sensors, three-wire NPN sensors
Input logic
Active low
Current consumption (see note)
120 mA max. with all input terminals ON
Input voltage range
0 VDC to supply voltage
Input current range
–5.3 to –3.6 mA/point
ON/OFF threshold
No-contact input:
ON voltage:
5.5 V max.
OFF voltage:
7.5 V min.
Contact input:
ON discrimination resistance:
1 kΩ
max.
OFF discrimination resistance: 2.1 k
Ω
min.
Note:
Consumption when all 10 points are ON. Excludes external sensor current for Input T
erminals.
