Omron CJ1G/H-CPU series - Page 112

79
Specifications Section 2-1
Interrupt inputs 2121
PWM output points 21None
Maximum subroutine
number
1,024 256 1,024 256
Maximum jump
number for JMP
instruction
1,024 256 1,024 256
Built-in inputs 10
• Interrupt inputs (quick-response): 4 inputs
• High-speed counter: 2 inputs (differential-
phase at 50 kHz or single-phase at 100 kHz)
---
Built-in outputs 6
• Pulse outputs: 2 at 100 kHz
• PWM outputs: 2
6
• Pulse out-
puts: 2 at
100 kHz
• PWM out-
puts: 1
---
Function
blocks
Maxi-
mum No.
of defini-
tions
128
Maxi-
mum No.
of
instances
256
Flash
memory
FB pro-
gram
memory
(Kbytes)
256
Com-
ment files
(Kbytes)
64
Program
index
files
(Kbytes)
64
Symbol
tables
(Kbytes)
64
Current
consumption
(
supplied by Power
Supply Units)
0.64 A at 5 V DC 0.58 A at 5 V DC
Connector
(provided)
One RS-232C Connector (Plug: XM2A-0901, Hood: XM2S-0911-E) provided with CPU Unit as
standard
Item Specification
CPU Units with Built-in I/O CPU Units without Built-in I/O
