Omron CJ1G/H-CPU series - Dimensions (Unit: MM)

193
B7A Interface Unit Section 3-7
Power Supply on Both Sides (Separate Power Supplies)
3-7-11 Dimensions (Unit: mm)
V1
SIG1
G1
V2
SIG2
G2
V3
SIG3
G3
V4
SIG4
G4
V
G
+
+
Ground
Shielded cable:
VCTF 0.75mm
2
min.
Transmission distance:
100 m max.
Ground
Shielded cable:
VCTF 0.75mm
2
min.
B7A Interface Unit
12 to 24 V DC
B7A Link Terminal
B7A Link Terminal
12 to 24 V DC
12 to 24 V DC
20
902.7 2.7
65
79.5
