Omron CJ1G/H-CPU series - Current Consumption Tables

129
Unit Current Consumption Section 2-6
2-6-3 Current Consumption Tables
5-V DC Voltage Group
Note The NT-AL001 Link Adapter consumes 0.15 A/Unit when used.
CJ-series Basic I/O Units
Name Model Current consumption (A)
CPU Units (including power
supplied to Programming
Console)
CJ1H-CPU66H 0.99 (See note.)
CJ1H-CPU65H 0.99 (See note.)
CJ1G-CPU45H 0.91 (See note.)
CJ1G-CPU44H 0.91 (See note.)
CJ1G-CPU43H 0.91 (See note.)
CJ1G-CPU42H 0.91 (See note.)
CJ1M-CPU23 0.64 (See note.)
CJ1M-CPU22 0.64 (See note.)
CJ1M-CPU21 0.64 (See note.)
CJ1M-CPU13 0.58 (See note.)
CJ1M-CPU12 0.58 (See note.)
CJ1M-CPU11 0.58 (See note.)
CJ1G-CPU45 0.91 (See note.)
CJ1G-CPU44 0.91 (See note.)
I/O Control Unit CJ1W-IC101 0.02
I/O Interface Unit CJ1W-II101 0.13
End Cover CJ1W-TER01 Included with CPU Unit or I/O Inter-
face Unit power supply.
Category Name Model Current
consumption (A)
Basic Input Units DC Input Units CJ1W-ID201 0.08
CJ1W-ID211 0.08
CJ1W-ID231 0.09
CJ1W-ID232 0.09
CJ1W-ID261 0.09
CJ1W-ID262 0.09
AC Input Units CJ1W-IA111 0.09
CJ1W-IA201 0.08
Interrupt Input Unit CJ1W-INT01 0.08
Quick-response
Input Unit
CJ1W-IDP01 0.08
B7A Interface Unit CJ1W-B7A14 0.07
