2-6 Unit Current Consumption
The amount of current/power that can be supplied to the Units mounted in a
Rack is limited by the capacity of the Rack’s Power Supply Unit. Refer to the
following tables when designing your system so that the total current con-
sumption of the mounted Units does not exceed the maximum current for
each voltage group and the total power consumption does not exceed the
maximum for the Power Supply Unit.
2-6-1 CJ-series CPU Racks and Expansion Racks
The following table shows the maximum currents and power that can be sup-
plied by Power Supply Units in CPU Racks and Expansion Racks.
When calculating current/power consumption in a CPU Rack, be sure to
include the power required by the CPU Unit itself, as well as the I/O Control
Unit if one or more Expansion Racks is connected. Likewise, be sure to
include the power required by the I/O Interface Unit when calculating current/
power consumption in an Expansion Rack.
Network Communications Max. baud rate Commu-
nica-
tions
distance
Max.
No.
of
Units
Commu-
nica-
tions
medium
Data link
capacity
(per net-
work)
Max.
remote
I/O
points
Connectable devices
Mes-
sages
Data
link
Re-
mote
I/O
Ethernet Yes --- --- 10 Mbps 2.5 km --- Twisted-
pair
--- --- Host computer-to-
PLC, PLC-to-PLC
100 Mbps 100 m --- --- ---
Controller
Link
Yes Yes --- 2 Mbps Twisted-
pair
cables:
500 m
32 Special
(twisted-
pair)
cables
32,000
words
--- PLC-to-PLC, personal
computer-to-PLC
DeviceNet Yes --- Yes 500 Kbps
Communications
cycle: Approx. 5
ms (128 inputs,
128 outputs)
100 m 63 Special
cables
--- 2,048 PLC-to-Slave
(Slaves: Remote I/O
Terminals, Remote
Adapters. Sensor Ter-
minals, CQM1 I/O Link
Units, Analog Output
Terminals, Analog
Input Terminals)
Compo-
Bus/S
--- --- Yes 750 Kbps
Communications
cycle: Approx. 1
ms max. (128
inputs, 128 out-
puts)
100 m 32 Two-core
wires,
special
flat
cables
--- 256 PLC-to-Slave
(Slaves: Remote I/O
Terminals, Remote I/O
Modules, Sensor Ter-
minals, Sensor Amp
Terminals, Bit Chain
Terminals)
PROFI-
BUS-DP
--- --- Yes 12 Mbps Commu-
nications cycle:
Approx. 3.5 ms
max. (128 inputs,
128 outputs)
100 m 125 Special
cables
--- 7,168
words
PLC-to-Slave (Slaves:
All PROFIBUS-DP
slaves)
Power Supply
Unit
Max. current consumption Max. total
power
consumption
5-V group
(Internal logic)
24-V group
(Relays)
24-V group
(Service)
CJ1W-PA205R 5.0 A 0.8 A None 25 W
CJ1W-PA202 2.8 A 0.4 A None 14 W
CJ1W-PD025 5.0 A 0.8 A None 25 W
