106
I/O Units Section 2-4
Basic Output Units
Name Specifications Model Number
of bits
allocated
Mountable Racks
CJ-series
CPU Rack
CJ-series
Expansion
Racks
Relay Output Units Terminal block, 250 V AC/24 V DC, 2 A;
8 points, independent contacts
CJ1W-OC201 16 (See
note 2.)
Ye s Ye s
Terminal block, 250 V AC, 0.6 A; 8 points CJ1W-OC211 16 Yes Yes
Triac Output Unit Terminal block, 250 V AC, 0.6 A/24 V DC, 2
A; 8 points, independent contacts
CJ1W-OA201 16 (See
note 2.)
Ye s Ye s
Tran sis -
tor Out-
put Units
Sinking
outputs
Terminal block, 12 to 24 V DC, 2 A, 8 outputs CJ1W-OD201 16 (See
note 2.)
Ye s Ye s
Terminal block, 12 to 24 V DC, 0.5 A,
8 outputs
CJ1W-OD203 16 (See
note 2.)
Ye s Ye s
Terminal block, 12 to 24 V DC, 0.5 A,
16 outputs
CJ1W-OD211 16 Yes Yes
Fujitsu-compatible connector, 12 to 24 V DC,
0.5 A, 32 outputs (See note 1.)
CJ1W-OD231 32 Yes Yes
MIL connector, 12 to 24 V DC, 0.3 A,
32 outputs (See note 1.)
CJ1W-OD233 32 Yes Yes
Fujitsu-compatible connector, 12 to 24 V DC,
0.3 A, 64 outputs (See note 1.)
CJ1W-OD261 64 Yes Yes
MIL connector, 12 to 24 V DC, 0.3 A,
64 outputs (See note 1.)
CJ1W-OD263 64 Yes Yes
Sourcing
outputs
Terminal block, 24 V DC, 2 A, 8 outputs, load
short-circuit protection and disconnected line
detection
CJ1W-OD202 16 (See
note 2.)
Ye s Ye s
Terminal block, 24 V DC, 0.5 A, 8 outputs,
load short-circuit protection
CJ1W-OD204 16 (See
note 2.)
Ye s Ye s
Terminal block, 24 V DC, 0.5 A, 16 outputs,
load short-circuit protection
CJ1W-OD212 16 Yes Yes
MIL connector, 24 V DC, 0.5 A, 32 outputs,
load short-circuit protection (See note 1.)
CJ1W-OD232 32 Yes Yes
MIL connector, 12 to 24 V DC, 0.3 A, 64 out-
puts (See note 1.)
CJ1W-OD262 64 Yes Yes
B7A Interface Units 64 outputs CJ1W-B7A04 64 Yes Yes
To Next Page
