109
I/O Units Section 2-4
Note The Space Unit is for Position Control Units.
Position
Control
Units
1 axis, pulse output; open col-
lector output
CJ1W-NC113 10 words 100
words
Yes Yes 0 to 95
2 axes, pulse outputs; open
collector outputs
CJ1W-NC213 10 words 100
words
Yes Yes 0 to 95
4 axes, pulse outputs; open
collector outputs
CJ1W-NC413 20 words 200
words
Yes Yes 0 to 94
(uses words
for 2 unit
numbers)
1 axis, pulse output; line
driver output
CJ1W-NC133 10 words 100
words
Yes Yes 0 to 95
2 axes, pulse outputs; line
driver outputs
CJ1W-NC233 10 words 100
words
Yes Yes 0 to 95
4 axes, pulse outputs; line
driver outputs
CJ1W-NC433 20 words 200
words
Yes Yes 0 to 94
(uses words
for 2 unit
numbers)
Space Unit (See note.) CJ1W-SP001 None None Yes Yes ---
ID Sen-
sor Units
V600-series single-head type CJ1W-
V600C11
10 words 100
words
Yes Yes 0 to 95
V600-series two-head type CJ1W-
V600C12
20 words 200
words
Yes Yes 0 to 94
(uses words
for 2 unit
numbers)
High-
speed
Counter
Unit
Two-axis pulse input, count-
ing rate: 500 kcps max., line
driver compatible
CJ1W-CT021 40 words 400
words
Yes Yes 0 to 92
(uses words
for 4 unit
numbers)
Compo-
Bus/S
Master
Units
CompoBus/S Remote I/O,
256 bits max.
CJ1W-SRM21 10 words
or 20
words
None Yes Yes 0 to 95 or
0 to 94
Name Specifications Model Number of
words
allocated
(CIO 2000
to
CIO 2959)
Number
of words
allocated
(D20000
to
D29599)
Mountable Racks
Unit No.
CJ-series
CPU Rack
CJ-series
Expansion
Racks
