Omron CJ1G/H-CPU series - Installation and Wiring

176
CJ-series Basic I/O Units Section 3-6
64-point Units (Input Units, Output Units, 24-V DC Input/Transistor Output Units, TTL I/O Units )
■ Units with Fujitsu-compatible Connector (40-pin x 2)
CJ1W-ID261 (64 inputs: 24 V DC)
CJ1W-OD261 (64 outputs: 12 to 24 V DC, 0.3 A)
CJ1W-MD261 (32 inputs: 24 V DC, 32 outputs: 12 to 24 V DC, 0.3 A)
■ Units with MIL Connector (40-pin x 2)
CJ1W-ID262 (64 inputs: 24 V DC)
CJ1W-OD262 (64 outputs: 12 to 24 V DC, 0.3 A)
CJ1W-OD263 (64 outputs: 12 to 24 V DC, 0.3 A)
CJ1W-MD263 (32 inputs: 24 V DC, 32 outputs: 12 to 24 V DC, 0.3 A)
CJ1W-MD563 (32 TTL inputs, 32 TTL outputs (5 V DC, 35 mA))
ABAB
1
20
1
20
24 VDC 0.3 A
INOUT
15
1
24 VDC 4.1 mA
MD261
CN1
0
CN2
2
3
12345670
8 9 10 11 12 13 14 15
12345670
8 9 10 11 12 13 14
65
66.5
(112.5)
90 2.72.7
31
OUT
5 VDC
3.5 mA
0 ch
1 ch 2 ch
3 ch
5 VDC
3.5 mA
12345670
8 9 10 11 12 13 14 15
12345670
8 9 10 11 12 13 14 15
31
MD563
20
IN
83.6
65
90 2.72.7
31
