273
PLC Setup Section 7-1
7-1-2-5 SIOU Refresh Tab Page
Spec ial I/O Unit Cyclic Refreshing
7-1-2-6 Unit Settings Tab Page
Basic I/O Unit Input (Rack) Response Times
Item Address in
Programming
Console
Settings Function Related
flags and
words
When set-
ting is
read by
CPU Unit
Word Bit(s)
Cyclic Refresh-
ing of Units 0 to
15
226 0 to 15 0: Enabled
1: Disabled
Default: 0
These settings determine whether
data will be exchanged between the
specified Unit and the Special I/O
Unit’s allocated words (10 words/
Unit) during cyclic refreshing for Spe-
cial I/O Units.
Turn ON the corresponding bit to dis-
able cyclic refreshing when the Unit
will be refreshed in an interrupt task
by IORF(097), several Special I/O
Units are being used and you don’t
want to extend the cycle time, or the
cycle time is so short that the Special
I/O Units internal processing can’t
keep up.
(Special I/O Units can be refreshed
from the program with IORF(097).)
--- At start of
operation.
Cyclic Refresh-
ing of Units 16
to 31
227 0 to 15 0: Enabled
1: Disabled
Default: 0
Cyclic Refresh-
ing of Units 32
to 47
228 0 to 15 0: Enabled
1: Disabled
Default: 0
Cyclic Refresh-
ing of Units 48
to 63
229 0 to 15 0: Enabled
1: Disabled
Default: 0
Cyclic Refresh-
ing of Units 64
to 79
230 0 to 15 0: Enabled
1: Disabled
Default: 0
Cyclic Refresh-
ing of Units 80
to 95
231 0 to 15 0: Enabled
1: Disabled
Default: 0
Item Address in
Programming
Console
Settings Function Related
flags and
words
When
setting is
read by
CPU Unit
Word Bit(s)
Rack 0, Slot 0 10 0 to 7 00: 8 ms
10: 0 ms
11: 0.5 ms
12: 1 ms
13: 2 ms
14: 4 ms
15: 8 ms
16: 16 ms
17: 32 ms
Default:
00 (8 ms)
Sets the input response time
(ON response time = OFF
response time) for CJ-series
Basic I/O Units. The default
setting is 8 ms and the setting
range is 0 ms to 32 ms.
This value can be increased to
reduce the effects of chatter-
ing and noise, or it can be
reduced to allow reception of
shorter input pulses.
A220 to
A259:
Actual
input
response
times for
Basic I/O
Units
At startup.
Rack 0, Slot 1 8 to 15
Rack 0, Slot 2 11 0 to 7
Rack 0, Slot 3 8 to 15
Rack 0, Slot 4 12 0 to 7
Rack 0, Slot 5 8 to 15
Rack 0, Slot6 13 0 to 7
Rack 0, Slot 7 8 to 15
Rack 0, Slot 8 14 0 to 7
Rack 0, Slot 9 8 to 15
Rack 1, Slots 0 to 9 15 to 19 See
Rack 0.
Rack 2, Slots 0 to 9 20 to 24
Rack 3, Slots 0 to 9 25 to 29
Rack 4, Slots 0 to 9 30 to 34
Rack 5, Slots 0 to 9 35 to 39
Rack 6, Slots 0 to 9 40 to 44
Rack 7, Slots 0 to 9 45 to 49
