97
Basic System Configuration Section 2-3
Units
Name Model Specifications
CJ1-H CPU Units CJ1H-CPU76H I/O bits: 2,560, Program capacity: 250 Ksteps
Data Memory: 448 Kwords (DM: 32 Kwords, EM: 32 Kwords × 13 banks)
CJ1H-CPU66H I/O bits: 2,560, Program capacity: 120 Ksteps
Data Memory: 256 Kwords (DM: 32 Kwords, EM: 32 Kwords × 7 banks)
CJ1H-CPU65H I/O bits: 2,560, Program capacity: 60 Ksteps
Data Memory: 128 Kwords (DM: 32 Kwords, EM: 32 Kwords × 3 banks)
CJ1G-CPU45H I/O bits: 1,280, Program capacity: 60 Ksteps
Data Memory: 128 Kwords (DM: 32 Kwords, EM: 32 Kwords × 3 banks)
CJ1G-CPU44H I/O bits: 1,280, Program capacity: 30 Ksteps
Data Memory: 64 Kwords (DM: 32 Kwords, EM: 32 Kwords × 1 banks)
CJ1G-CPU43H I/O bits: 960, Program capacity: 20 Ksteps
Data Memory: 64 Kwords (DM: 32 Kwords, EM: 32 Kwords × 1 banks)
CJ1G-CPU42H I/O bits: 960, Program capacity: 10 Ksteps
Data Memory: 64 Kwords (DM: 32 Kwords, EM: 32 Kwords × 1 banks)
CJ1M CPU Units CJ1M-CPU23 I/O bits: 640, Program capacity: 20 Ksteps
Data Memory: 32 Kwords (DM: 32 Kwords, EM: None), built-in pulse I/O
CJ1M-CPU22 I/O bits: 320, Program capacity: 10 Ksteps
Data Memory: 32 Kwords (DM: 32 Kwords, EM: None), built-in pulse I/O
CJ1M-CPU21 I/O bits: 160, Program capacity: 5 Ksteps
Data Memory: 32 Kwords (DM: 32 Kwords, EM: None), built-in pulse I/O
CJ1M-CPU13 I/O bits: 640, Program capacity: 20 Ksteps
Data Memory: 32 Kwords (DM: 32 Kwords, EM: None)
CJ1M-CPU12 I/O bits: 320, Program capacity: 10 Ksteps
Data Memory: 32 Kwords (DM: 32 Kwords, EM: None)
CJ1M-CPU11 I/O bits: 160, Program capacity: 5 Ksteps
Data Memory: 32 Kwords (DM: 32 Kwords, EM: None)
CJ1 CPU Units CJ1G-CPU45 I/O bits: 1,280, Program capacity: 60 Ksteps
Data Memory: 128 Kwords (DM: 32 Kwords, EM: 32 Kwords × 3 banks)
CJ1G-CPU44 I/O bits: 1,280, Program capacity: 30 Ksteps
Data Memory: 64 Kwords (DM: 32 Kwords, EM: 32 Kwords × 1 banks)
CJ-series
Power Supply Units
CJ1W-PA205R 100 to 240 V AC (with RUN output), Output capacity: 5 A at 5 V DC
CJ1W-PA202 100 to 240 V AC, Output capacity: 2.8A at 5 V DC
CJ1W-PD025 24 V DC, Output capacity: 5 A at 5 V DC
Memory Cards HMC-EF172 Flash memory, 15 MB
HMC-EF372 Flash memory, 30 MB
HMC-EF672 Flash memory, 64 MB
HMC-AP001 Memory Card Adapter
I/O Control Unit CJ1W-IC101 Required to connect an Expansion Rack. Must be connected next to the
CPU Unit. Connect to the I/O Interface Unit (CJ1W-II101) on the first
Expansion Rack with a CS/CJ-series I/O Connecting Cable.
End Cover CJ1W-TER01 Must be connected to the right end of the CPU Rack. One End Cover is
provided with the CPU Unit and with an I/O Interface Unit.
A fatal error will occur if the End Cover is not connected.
DIN Track PFP-50N Track length: 50 cm, height: 7.3 mm
PFP-100N Track length: 1 m, height: 7.3 mm
PFP-100N2 Track length: 1 m, height: 16 mm
PFP-M Stopper to prevent Units from moving on the track. Two each are pro-
vided with the CPU Unit and with an I/O Interface Unit.
To Next Page
