98
Basic System Configuration Section 2-3
Note A peripheral bus connection is not possible when connecting the CX-Pro-
grammer via an RS-232C Connecting Cable. Use the Host Link (SYSMAC
WAY) connection.
Programming Con-
soles
CQM1H-PRO01-E An English Keyboard Sheet (CS1W-KS001-E) is required.
CQM1-PRO01-E
C200H-PRO27-E
Programming Con-
sole Keyboard Sheet
CS1W-KS001-E For CQM1H-PRO01-E, CQM1-PRO01-E, or C200H-PRO27-E.
Programming Con-
sole Connecting
Cables
CS1W-CN114 Connects the CQM1-PRO01-E Programming Console.
(Length: 0.05 m)
CS1W-CN224 Connects the CQM1-PRO27-E Programming Console.
(Length: 2.0 m)
CS1W-CN624 Connects the CQM1-PRO27-E Programming Console.
(Length: 6.0 m)
Programming Device
Connecting Cables
(for peripheral port)
CS1W-CN118 Connects DOS computers
D-Sub 9-pin receptacle (For converting between RS-232C cable and
peripherals)
(Length: 0.1 m)
CS1W-CN226 Connects DOS computers
D-Sub 9-pin (Length: 2.0 m)
CS1W-CN626 Connects DOS computers
D-Sub 9-pin (Length: 6.0 m)
Programming Device
Connecting Cables
(for RS-232C port)
XW2Z-200S-CV Connects DOS computers
D-Sub 9-pin (Length: 2.0 m), Static-resistant connector used.
XW2Z-500S-CV Connects DOS computers
D-Sub 9-pin (Length: 5.0 m), Static-resistant connector used.
XW2Z-200S-V Connects DOS computers
D-Sub 9-pin (Length: 2.0 m) (see note)
XW2Z-500S-V Connects DOS computers
D-Sub 9-pin (Length: 5.0 m) (see note)
USB-Serial Conver-
sion Cable
CS1W-CIF31 Converts USB connector to a D-Sub 9-pin connector
(Length: 0.5 m)
Battery Set CPM2A-BAT01 Used for CJ1-H and CJ1 CPU Units, and also for CPM2A and CQM1H.
(Cannot be used with CS-series CPU Units.)
CJ1W-BAT01 Used for CJ1M CPU Units. (Cannot be used with CJ1-H and CJ1 CPU
Units.)
Name Model Specifications
To Next Page
