100
Basic System Configuration Section 2-3
Connecting Personal Computers Running Support Software
Connecting to Peripheral Port
Connecting to RS-232C Port
Programming Software
DOS
CS1W-CN118
CS1W-CN226
CS1W-CN626
RS-232C
XW2Z-200S-@@: 2 m
XW2Z-500S-@@: 5 m
0.1 m
2.0 m
6.0 m
Computer
Note
Connecting Cables for Peripheral Port
Cable Length Computer
connector
D-Sub,
9-pin
DOS computer
(RS-232C, 9-pin)
Peripheral
port
The CS1W-CN118 Cable is used with an RS-232C
cable to connect to the peripheral port on the CPU Unit
as shown below. The CS1W-CN118 Cable cannot be
used with an RS-232C cable whose model number
ends in -V for a peripheral bus connection and must be
used for a Host Link (SYSMAC WAY) connection.
RS-232C Cable
CS1W-CN118 Cabl
Peripheral
port
DOS 2.0 m
5.0 m
Cable
Note
DOS version
(RS-232C, 9-pin)
RS-232C Cable
XW2Z-200S-CV
or XW2Z-200S-V: 2 m
XW2Z-500S-CV
or XW2Z-500S-V: 5 m
Connecting Cables for RS-232C Port
Computer Length
Computer
connector
D-Sub,
9-pin
XW2Z-500S-CV
or XW2Z-500S-V
XW2Z-200S-CV
or XW2Z-200S-V
The XW2Z-200S-CV and XW2Z-500S-CV use static-
resistant connectors and can be connected to the
peripheral bus or the Host Link. The XW2Z-200S-V
and XW2Z-500S-V, however, can only be connected
to the Host Link, not the peripheral bus.
RS-232C port
OS Name
Windows CX-Programmer
CJ1 CPU Units: Version 2.04 or higher
CJ1-H CPU Units: Version 2.1 or higher
CJ1M CPU Units: Version 3.0 or higher
CD-ROM
