177

CJ-series Basic I/O Units Section 3-6

Connecting to Connector-Terminal Block Units

The CJ-series 32/64-point Basic I/O Units can be connected to Connector-

Terminal Block Conversion Units as shown in the following table.

Units with Fujitsu-compatible Connectors

Basic I/O Unit Connecting

Cable

Connector-Terminal Block Conversion Unit Required for

connection

Model

number

Specifications Model number Specifications

CJ1W-

ID231

32-point 24-V DC Input

Unit

XW2Z-@@@B XW2B-40G5 Standard, M3.5 screw terminal block 1 Connecting Cable

and 1 Conversion Unit

XW2B-40G4 Standard, M3 screw terminal block

XW2D-40G6 Slim, M3 screw terminal block

XW2D-40G6-RF Slim, M3 screw terminal block, built-

in bleeder resistor

XW2Z-@@@D XW2C-20G5-IN16 16-point input common, M3.5 screw

terminal block

1 Connecting Cable

and 2 Conversion Units

CJ1W-

ID261

64-point 24-V DC Input

Unit

XW2Z-@@@B XW2B-40G5 Standard, M3.5 screw terminal block 2 Connecting Cables

and 2 Conversion Units

XW2B-40G4 Standard, M3 screw terminal block

XW2D-40G6 Slim, M3 screw terminal block

XW2D-40G6-RF Slim, M3 screw terminal block, built-

in bleeder resistor

XW2Z-@@@D XW2C-20G5-IN16 16-point input common, M3.5 screw

terminal block

2 Connecting Cables

and 4 Conversion Units

CJ1W-

OD231

32-point Transistor Out-

put Unit with Sinking

Outputs

XW2Z-@@@B XW2B-40G5 Standard, M3.5 screw terminal block 1 Connecting Cable

and 1 Conversion Unit

XW2B-40G4 Standard, M3 screw terminal block

XW2D-40G6 Slim, M3 screw terminal block

CJ1W-

OD261

64-point Transistor Out-

put Unit with Sinking

Outputs

XW2Z-@@@B XW2B-40G5 Standard, M3.5 screw terminal block 2 Connecting Cables

and 2 Conversion Units

XW2B-40G4 Standard, M3 screw terminal block

XW2D-40G6 Slim, M3 screw terminal block

CJ1W-

MD231

16-point 24-V DC Input/

16-point Transistor Out-

put Unit with Sinking

Outputs

Inputs:

XW2Z-@@@A

XW2B-20G4 Standard, M3 screw terminal block 1 Connecting Cable

and 1 Conversion Unit

XW2B-20G5 Standard, M3.5 screw terminal block

XW2D-20G6 Slim, M3 screw terminal block

XW2C-20G5-IN16 2-tier, M3.5 screw terminal block

Outputs:

XW2Z@@@A

XW2B-20G4 Standard, M3 screw terminal block

XW2B-20G5 Standard, M3.5 screw terminal block

XW2D-20G6 Slim, M3 screw terminal block

CJ1W-

MD261

32-point 24-V DC Input/

32-point Transistor Out-

put Unit with Sinking

Outputs

Inputs:

XW2Z-@@@B

XW2B-40G4 Standard, M3 screw terminal block 1 Connecting Cable

and 1 Conversion Unit

XW2B-40G5 Standard, M3.5 screw terminal block

XW2D-40G6 Slim, M3 screw terminal block

XW2D-40G6-RF Slim, M3 screw terminal block, built-

in bleeder resistor

Inputs:

XW2Z-

@@@D

XW2C-20G5-IN16 2-tier, M3.5 screw terminal block 1 Connecting Cable

and 2 Conversion Units

Outputs:

XW2Z-@@@B

XW2B-40G4 Standard, M3 screw terminal block 1 Connecting Cable

and 1 Conversion Unit

XW2B-40G5 Standard, M3.5 screw terminal block

XW2D-40G6 Slim, M3 screw terminal block
