178
CJ-series Basic I/O Units Section 3-6
Units with MIL Connectors
Basic I/O Unit Connecting
Cable
Connector-Terminal Block Conversion Unit Required for
connection
Model
number
Specifications Model number Specifications
CJ1W-
ID232
32-point 24-V DC
Input Unit
XW2Z-@@@K XW2B-40G5 Standard, M3.5 screw terminal block 1 Connecting Cable
and 1 Conversion Unit
XW2B-40G4 Standard, M3 screw terminal block
XW2D-40G6 Slim, M3 screw terminal block
XW2D-40G6-RM Slim, M3 screw terminal block, built-
in bleeder resistor
XW2Z-@@@N XW2C-20G5-IN16 16-point input common, M3.5 screw
terminal block
1 Connecting Cable
and 2 Conversion Units
XW2C-20G6-IO16 16-point I/O common, M3.5 screw
terminal block
CJ1W-
ID262
64-point 24-V DC
Input Unit
XW2Z-@@@K XW2B-40G5 Standard, M3.5 screw terminal block 2 Connecting Cables
and 2 Conversion Units
XW2B-40G4 Standard, M3 screw terminal block
XW2D-40G6 Slim, M3 screw terminal block
XW2D-40G6-RM Slim, M3 screw terminal block, built-
in bleeder resistor
XW2Z-@@@N XW2C-20G5-IN16 16-point input common, M3.5 screw
terminal block
2 Connecting Cables
and 4 Conversion Units
XW2C-20G6-IO16 16-point I/O common, M3.5 screw
terminal block
CJ1W-
OD232
32-point Transistor
Output Unit with
Sourcing Outputs
XW2Z-@@@K XW2B-40G5 Standard, M3.5 screw terminal block 1 Connecting Cable
and 1 Conversion Unit
XW2B-40G4 Standard, M3 screw terminal block
XW2D-40G6 Slim, M3 screw terminal block
XW2Z-@@@N XW2C-20G6-IO16 16-point I/O common, M3.5 screw
terminal block
1 Connecting Cable
and 2 Conversion Units
CJ1W-
OD233
32-point Transistor
Output Unit with
Sinking Outputs
XW2Z-@@@K XW2B-40G5 Standard, M3.5 screw terminal block 1 Connecting Cable
and 1 Conversion Unit
XW2B-40G4 Standard, M3 screw terminal block
XW2D-40G6 Slim, M3 screw terminal block
XW2Z-
@@@N XW2C-20G6-IO16 16-point I/O common, M3.5 screw
terminal block
1 Connecting Cable
and 2 Conversion Units
CJ1W-
OD262
64-point Transistor
Output Unit with
Sourcing Output
XW2Z-@@@K XW2B-40G4 Standard, M3 screw terminal block 2 Connecting Cables
and 2 Conversion Units
XW2B-40G5 Standard, M3.5 screw terminal block
XW2D-40G6 Slim, M3 screw terminal block
XW2Z-@@@N XW2C-20G6-IO16 16-point I/O common, M3.5 screw
terminal block
2 Connecting Cables
and 4 Conversion Units
CJ1W-
OD263
64-point Transistor
Output Unit with
Sinking Outputs
XW2Z-@@@K XW2B-40G5 Standard, M3.5 screw terminal block 2 Connecting Cable
and 2 Conversion Unit
XW2B-40G4 Standard, M3 screw terminal block
XW2D-40G6 Slim, M3 screw terminal block
XW2Z-@@@N XW2C-20G6-IO16 16-point I/O common, M3.5 screw
terminal block
2 Connecting Cables
and 4 Conversion Units
CJ1W-
MD232
16-point 24-V DC
Input/16-point Tran-
sistor Output Unit
with Sourcing Out-
puts
Inputs:
G79-O@@C
XW2B-20G4 Standard, M3 screw terminal block 1 Connecting Cable
and 1 Conversion Unit
XW2B-20G5 Standard, M3.5 screw terminal block
XW2D-20G6 Slim, M3 screw terminal block
Outputs:
G79-O@@C
XW2B-20G4 Standard, M3 screw terminal block
XW2B-20G5 Standard, M3.5 screw terminal block
XW2D-20G6 Slim, M3 screw terminal block
CJ1W-
MD233
16-point 24-V DC
Input/16-point Tran-
sistor Output Unit
with Sinking Outputs
Inputs:
G79-O@@C
XW2B-20G4 Standard, M3 screw terminal block 1 Connecting Cable
and 1 Conversion Unit
XW2B-20G5 Standard, M3.5 screw terminal block
XW2D-20G6 Slim, M3 screw terminal block
Outputs:
G79-O@@C
XW2B-20G4 Standard, M3 screw terminal block
XW2B-20G5 Standard, M3.5 screw terminal block
XW2D-20G6 Slim, M3 screw terminal block
To Next Page
