Omron CJ1M-CPU series User Manual

227
Installation Section 5-2
64-point Basic I/O Units, MIL Connector
CJ1W-MD263 (32 inputs/32 outputs)
CJ1W-MD563 (32 TTL inputs/32 TTL outputs)
B7A Interface Units
CJ1W-B7A14 (64 inputs (4 B7A ports))
CJ1W-B7A04 (64 outputs (4 B7A ports))
CJ1W-B7A22 (32 inputs/32 outputs (4 B7A ports))
OUT
5 VDC
3.5 mA
0 ch
1 ch 2 ch
3 ch
5 VDC
3.5 mA
12345670
8 9 10 11 12 13 14 15
12345670
8 9 10 11 12 13 14 15
31
MD563
20
IN
83.6
65
90 2.72.7
31
20
902.7 2.7
65
79.5
