4 Troubleshooting and Maintenance
CJ-series PROFIBUS Slave Unit Operation Manual for NJ-series CPU Unit (W510)
4-3 Event Logs
4
4-3-2 Error Table
Event code Event name Meaning Assumed cause
Level
Maj Prt Min Obs Info
38180000 hex Parame-
ter/Configu-
ration Error
The Slave has
received incorrect
parameter and/or
configuration mes-
sages from a Mas-
ter Unit.
Parameter Error can be caused by:
• Invalid standard parameter settings (valid
settings are described in the PROFIBUS
standard).
• Invalid user parameter settings (allowed
settings are described in the GSD file of
the Unit).
• Incorrect start addresses for I/O data in
the host CPU system. If one of them is
invalid, parameter error is indicated, plus
*_StartAdrInErr and/or *_StartAdrOutErr
will be set.
Configuration Error can be caused by:
• Input - or output length > 100 words
• Input + output length > 180 words
• Input length < 2 words while CPU status
should be included.
• Input - or output length causing errors
indicated by *_EndAdrInErr,
*_EndAdrOutErr
X
