Omron CJ1W-PRT21 - External Dimensions

2-7
2 Nomenclature and Installation
CJ-series PROFIBUS Slave Unit Operation Manual for NJ-series CPU Unit (W510)
2-2 Installing the PROFIBUS-DP Slave Unit
2
2-2-4 External Dimensions
2-2-4 External Dimensions
MACH
NODE
x10
1
x10
0
x10
1
x10
0
RUN
ERC
COMM
ERH BF
90 mm
31 mm
Bus
65 mm
No.
PRT21
No.
5 mm
