A-3 Parameterization by the PROFIBUS
Master Unit
The parameterisation of the passive stations by the master is first done in the start-up phase of the
PROFIBUS-DP system and is also possible in the data exchange mode. The first 10 bytes of parameter
data are defined by the PROFIBUS standard the additional 9 bytes are device specific. The format of
the parameters is depicted in the following table.
Although the Unit does not support PROFIBUS-DP/V1 functionality, the three DPV1 status bytes are
reserved in the Set_Prm message. Only the 2 indicated bits can be set by the user.
Byte
Bit Position
Designation
7 6 5 4 3 2 1 0
0 Lock
Req
Unlock
Req
Sync
Req
Freeze
Req
WD on Res Res Res Station status
1 00 to FF WD_Fact_1
2 00 to FF WD_Fact_2
3 MinTSDR
4 00 to FF Ident_Number_High
5 00 to FF Ident_Number_Low
6 00 to FF Group_Ident
70 Fail
Safe
000WD
1 ms
0 0 DPV1_Status_1
800000000 DPV1_Status_2
900000000 DPV1_Status_3
10 0 0 0 Motor-
ola/
Intel
0 0 0 Reset/
Hold
Output options*
11 codes to indicate CIO, H, W, D, E0 to EC Output Area*
12 00 to 7F Out start address High*
13 00 to FF Out start address Low*
14 Incl. Sta-
tus
00Motor-
ola/
Intel
Action Fatal Error
(Continue/Stop)
Action PRGmode
(Continue/Stop)
Input options*
15 codes to indicate CIO, H, W, D, E0-EC Input Area*
16 00 to 7F In start address High*
17 00 to FF In start address Low*
