Appendices
A-6
CJ-series PROFIBUS Slave Unit Operation Manual for NJ-series CPU Unit (W510)
DM + 5 to DM + 7 (Slave Input Settings)
The device variable for CJ-series Unit that corresponds to all bits of the words in DM+5 to DM + 7
are as follows:
The device variables for CJ-series Units that correspond to bits 0 to 15 of a each word in DM + 5 to
DM + 7 are as follows:
DM + 4 0 to 15 *_SlvOutDatLen Output data length
CJ-series I/O memory address NJ-series device variables for CJ-series Unit
Word address Bit Variable name Description
DM + 5 to DM + 7 0 to 15 for each
word
*_SlvInSta Slave Input Settings
CJ-series I/O memory address NJ-series device variables for CJ-series Unit
Word address Bit Variable name Description
DM + 5 0 to 7 *_SlvInAreaCode Input area code
8 *_SlvInProgCont Continue in PROGRAM mode
9 *_SlvInProgExit Exit in PROGRAM mode
10 *_SlvInFatlCont Continue on fatal error
11 *_SlvInFatlExit Exit on fatal error
12 *_SlvInIntelMd Inputs Intel mode
13 and 14 Undefined Reserved by system
15 *_SlvInclPLCSta Include PLC status in input data
DM + 6 0 to 15 *_SlvInStartAdr Input start address
DM + 7 0 to 15 *_SlvInDatLen Input data length
CJ-series I/O memory address NJ-series device variables for CJ-series Unit
Word address Bit Variable name Description
