3 Data Exchange with the CPU Unit
3-20
CJ-series PROFIBUS Slave Unit Operation Manual for NJ-series CPU Unit (W510)
3-7 Device Variables for CJ-series Unit
(Configuration)
The CJ1W-PRT21 provides 8 consecutive DM words to indicate configuration and parameterisation
data received from the PROFIBUS-DP master unit. These words are not part of the cyclic refresh, but
the unit writes this information to the Host CPU when the data in the unit changes. At power-on, or at a
reset of the unit, all data will be set to 0. The DM words are in the area assigned to the Special I/O unit,
depending on the Machine No (see section 3-5-1 Data Flow).
Name of Device Variable for CJ-
series Unit
Type R/W Description
*_SlvParamSta DWORD R Slave parameter data (see section 3-7-1)
*_SlvMstrAdr USINT R Bits 00-07: Master address
*_SlvGrp1 BOOL R Bit 08: Slave assigned to Group 1
*_SlvGrp2 BOOL R Bit 09: Slave assigned to Group 2
*_SlvGrp3 BOOL R Bit 10: Slave assigned to Group 3
*_SlvGrp4 BOOL R Bit 11: Slave assigned to Group 4
*_SlvGrp5 BOOL R Bit 12: Slave assigned to Group 5
*_SlvGrp6 BOOL R Bit 13: Slave assigned to Group 6
*_SlvGrp7 BOOL R Bit 14: Slave assigned to Group 7
*_SlvGrp8 BOOL R Bit 15: Slave assigned to Group 8
*_SlvWdtFact1 USINT R Bits 00 to 07: Watchdog factor 1
*_SlvWdtFact2 USINT R Bits 08 to 15: Watchdog factor 2
*_SlvOutSta LWORD R Slave Output Data (see section 3-7-2)
*_SlvOutAreaCode USINT R Bits 00 to 07: Output area code
*_SlvOutHoldBusErr BOOL R Bit 08: Data hold on PROFIBUS fail
*_SlvOutIntelMd BOOL R Bit 12: Outputs Intel mode
*_SlvOutStartAdr UINT R Output start address
*_SlvOutDatLen UINT R Output data length
*_SlvInSta LWORD R Slave Input Settings (see section 3-7-3)
*_SlvInAreaCode USINT R Bits 00 to 07: Input area code
*_SlvInProgCont BOOL R Bit 08: Continue in PROGRAM mode
*_SlvInProgExit BOOL R Bit 09: Exit in PROGRAM mode
*_SlvInFatlCont BOOL R Bit 10: Continue on fatal error
*_SlvInFatlExit BOOL R Bit 11: Exit on fatal error
*_SlvInIntelMd BOOL R Bit 12: Inputs Intel mode
*_SlvInclPLCSta BOOL R Bit 15: Include PLC status in input data
*_SlvInStartAdr UINT R Input start address
*_SlvInDatLen UINT R Input data length
