3 Data Exchange with the CPU Unit
CJ-series PROFIBUS Slave Unit Operation Manual for NJ-series CPU Unit (W510)
3-7 Device Variables for CJ-series Unit (Configuration)
3
3-7-3 Slave Input Settings (*_SlvInSta)
Name of Device Variable for CJ-
series Unit
Type R/W Description Function
*_SlvInStartAdr UINT R Input start
address
Indicates the start address in the area indicated
in *_SlvInSta, from which the PROFIBUS input
data will be read (data from Slave CPU to Mas-
ter).
The value is provided by the PROFIBUS mas-
ter's Set_Prm
telegram, and indicated in *_SlvInStartAdr after
both the Set_Prm and Chk_Cfg telegrams have
been accepted.
The indication is only valid in case the input
area code is unequal to 00.
The start address is indicated as a value in the
range 0 to 32767.
1514131211109876543210
*_SlvInDatLen
*_SlvInDatLen
Name of Device Variable for CJ-
series Unit
Type R/W Description Function
*_SlvInDatLen UINT R Input data
length
The value indicates the size of the area from
which the PROFIBUS input data will be read
(data from Slave CPU to Master).
The value is provided by the PROFIBUS mas-
ter's Chk_Cfg telegram, and indicated in
*_SlvInDatLen after both the Set_Prm and
Chk_Cfg telegrams have been accepted.
The indication is only valid in case the input
area code is unequal to 00.
The length (in words) is indicated as a value in
the range 0 to 100.
To Next Page
