12 Troubleshooting
12 - 18
NX-series EtherNet/IP Coupler Unit User’s Manual (W536)
01 0111 Error code returned from target:
The RPI was set to a value that
exceeds the specifications.
This error does not occur. Set the originator’s RPI setting to 10
seconds or less.
01 0113 Error code generated by originator
or returned from target:
Attempted to open more connec-
tions than allowed by the specifica-
tions (32).
Check the connection settings
(number of connections) at the
originator and target.
Check the connection settings (num-
ber of connections) at the originator
and target. Check the connection
specifications for devices from other
manufacturers.
01 0114 Error code returned from target:
The Vendor ID and Product Code
did not match when opening con-
nection.
This error does not occur. Check the originator’s connection
settings.
01 0115 Error code returned from target:
The Product Type did not match
when opening connection.
This error does not occur. Check the originator’s connection
settings.
01 0116 Error code returned from target:
The Major/Minor Revisions did not
match when opening connection.
Check the major and minor revi-
sions set for the target device
and connection. If necessary,
obtain the most recent EDS file
and set it again.
Check the originator’s connection
settings.
01 0117 Error code returned from target:
The tag set specified in the connec-
tion’s target variables does not exist.
Check whether the originator and
target tag sets and tags are set
correctly.
Check the originator’s connection
settings. Check whether the target
tag sets and tags are set correctly.
01 0118 Error code returned from the target:
There is a mistake in the size speci-
fied with the data segment included
in the connection path.
This error does not occur. Check the originator’s connection
settings.
01 0119 Error code returned from the target:
An attempt was made to open a lis-
ten only connection when there was
no connection other than a listen
only connection open.
Check the connection settings of all originator devices and see if an
Input/Output or Input Only connection is set.
01 011A Error code generated by originator:
Connection could not be established
because the buffer was full due to
high traffic.
Unexpected network traffic may
have been received. Use the Net-
work Configurator Device Monitor
or the Ethernet Tab Page to
check the bandwidth usage, and
correct the load. If there are
places where broadcast storms
occur, such as loop connections
in the network connection format,
then correct them.
Depends on the target’s specifica-
tions. (Contact the target device’s
manufacturer.)
01 011B Error code returned from target:
The RPI was set to a value that is
below the specifications.
This error does not occur. Set the originator’s RPI setting to 1
ms or greater.
01 0123 Error code returned from the target:
A request was received to open a
type of connection that is not sup-
ported (a connection type going from
the originator to the target).
This error does not occur. Check the originator’s connection
type. An error will occur if any type
other than multicast or point-to-point
is specified.
01 0124 Error code returned from the target:
A request was received to open a
type of connection that is not sup-
ported (a connection type going from
the target to the originator).
This error does not occur. Check the originator’s connection
type. An error will occur if any type
other than multicast or point-to-point
is specified.
01 0127 Error code returned from the target:
A different data size is set for the
connection in the originator and tar-
get (data from the originator to the
target).
Check the connection sizes set in the originator and target (data from the
originator to the target).
Connection status
Source of error
Handling
General
Status
(hex)
Additional
Status
(hex)
Configuration 1 Configuration 2
