Appendices
A - 74
NX-series EtherNet/IP Coupler Unit User’s Manual (W536)
The following tables give the relationship between the unit version of the EtherNet/IP Coupler Unit, the
Support Software that you can use, and the Support Software connection methods.
NX-EIC202 Ver.1.2
A-10-3 Unit Versions and Support Software
Purpose
NJ/NX/NY-series Controller CS/CJ/CP-series Controller
PLC from another manufac-
turer
Support
Software
Connection
Method
Support
Software
Connection
Method
Support
Software
Connection
Method
Programming Sysmac Stu-
dio Standard
Edition
• Connec-
tion to CPU
Unit
• Industrial
PC
• Ethernet
connection
CX-Program-
mer
• Connec-
tion to CPU
Unit
• Ethernet
connection
Support soft-
ware from
other com-
pany
Depends on
support soft-
ware from
other com-
pany.
EtherNet/IP
Network Con-
figuration
Sysmac Stu-
dio Standard
Edition and
Network Con-
figurator
• Connec-
tion to CPU
Unit
• Industrial
PC
• Ethernet
connection
Network Con-
figurator
• Connec-
tion to CPU
Unit
• Ethernet
connection
Support soft-
ware from
other com-
pany
Depends on
support soft-
ware from
other com-
pany.
EtherNet/IP
Coupler Unit
Configura-
tion and I/O
Mapping
NX-IO Con-
figurator
*1
• Connec-
tion to CPU
Unit
• Industrial
PC
• Ethernet
connection
• Connec-
tion to
peripheral
USB port
on Ether-
Net/IP
Coupler
Unit
NX-IO Con-
figurator
*2
• Connec-
tion to CPU
Unit
• Ethernet
connection
• Connec-
tion to
peripheral
USB port
on Ether-
Net/IP
Coupler
Unit
NX-IO Con-
figurator
*2
• Ethernet
connection
• Connec-
tion to
peripheral
USB port
on Ether-
Net/IP
Coupler
Unit
IO-Link Set-
tings
CX-Configu-
ratorFDT
• Connec-
tion to CPU
Unit
• Industrial
PC
• Ethernet
connection
• Connec-
tion to
peripheral
USB port
on Ether-
Net/IP
Coupler
Unit
CX-Configu-
ratorFDT
• Connec-
tion to CPU
Unit
• Ethernet
connection
• Connec-
tion to
peripheral
USB port
on Ether-
Net/IP
Coupler
Unit
CX-Configu-
ratorFDT
• Ethernet
connection
• Connec-
tion to
peripheral
USB port
on Ether-
Net/IP
Coupler
Unit
To Next Page
