NX-series EtherNet/IP Coupler Unit User’s Manual (W536)
A-1 Supported CIP Objects
A
A-1-3 NX Configuration Object (Class ID: 74 Hex)
Format for Error Response
CIP error code
 Change NX State (Service Code: 39 Hex)
The request format, format for normal responses, format for error responses, and CIP error codes
for the Change NX state object are given below.
Request Format
Reserved Reserved USINT 00
General Status Code that indicates normal USINT 00
Size of Additional Status Size of Additional status USINT 00
Total power on time Total power-ON time ULINT Total
power-ON time
Parameter name Description
Data
type
Value (hex)
Reply Service Reply to Switch parameter write mode
service
USINT B8
Reserved Reserved USINT 00
General Status Current error code defined by CIP USINT Current error code
Size of Additional Status Size of Additional status USINT
00
*1
*1. If the general status code in the response code is 0x1F (Vendor specific error), the value is 0x01.
Additional status Additional status UINT
Additional status
*2
*2. This is stored only when the value of Size of Additional Status is 0x01.
General status code (hex)
Error code
*1
*1. Refer to General Status Code on page A-30 for error descriptions.
02 Resource unavailable
13 Not enough data
15 Too much data
1F Vendor specific error
20 Invalid parameter
Parameter name Description Data type Value (hex)
Service Service code USINT 39
Request Path Size Request path size USINT 02
Request Path Request path Padded EPATH 20742401
Unit No Unit number UINT 0000: Communications Coupler
Unit
0001 or higher: Not supported.
State State of NX Unit BYTE 04: Safe-Operational
08: Operational
Reserved Reserved USINT 00
Output data access
watch dog timeout
time (ms)
Monitoring timeout time for
output data access
*1
*1. If the communications master does not write the output data within the access monitor timeout time, the
outputs from the NX Unit are stopped.
UDINT 0000000A to 0036EE80: Time-
out time
*2
Parameter name Description
Data
type
Value (hex)
