NX-series EtherNet/IP Coupler Unit User’s Manual (W536)
The terminal blocks that you can use with each model of the EtherNet/IP Coupler Unit are given in
the following table.
Precautions for Correct Use
Do not use the NX-TBA081 Terminal Block. The terminal current capacity of 4 A for that type is
not sufficient for the NX-EIC202.
To differentiate between the two models of terminal blocks, use the terminal number column indica-
tions. The terminal block with white letters on a dark background is the NX-TBC082.
Additional Information
Refer to A-9 Terminal Block Model Numbers on page A-65 for the screwless clamping terminal
blocks for EtherNet/IP Slave Terminals.
Applicable Terminal Blocks for Each Model
Unit model number
Terminal block
Terminal block
model number
Number of
terminals
Ground terminal
mark
Terminal current
capacity
NX-EIC202 NX-TBC082 8 Present 10 A
