EtherNet/IP Settings
10
■Input area
Address
Bit
Function name
D10100
Sensor head status signal 1 (lower 16 bits)
0
Control command completion
1
Reserved
2
Ready
3
Reserved
4
Run screen
5 to 10
Reserved
11
Current bank number bit0
12
Current bank number bit1
13
Current bank number bit2
14
Current bank number bit3
15
Current bank number bit4
D10101
Sensor head status signal 1 (upper 16 bits)
0
Error
1 to 15
Reserved
D10102
Sensor head status signal 2 (lower 16 bits)
0
Hold execution status
1
Reset execution state
2
Logical beam lighting state
3
Measurement position
4
Measurement state
5
Data output completed
6
Overall judgment result
7
Reserved
8
TASK1 TASK status
9
TASK2 TASK status
10
TASK3 TASK status
11
TASK4 TASK status
12 to 15
Reserved
D10103
Sensor head status signal 2 (upper 16 bits)
0
TASK1 Zero reset state
1
TASK2 Zero reset state
2
TASK3 Zero reset state
3
TASK4 Zero reset state
4
TASK1 HIGH output
5
TASK1 PASS output
6
TASK1 LOW output
7
TASK2 HIGH output
8
TASK2 PASS output
9
TASK2 LOW output
10
TASK3 HIGH output
11
TASK3 PASS output
12
TASK3 LOW output
13
TASK4 HIGH output
14
TASK4 PASS output
15
TASK4 LOW output
