EtherNet/IP Settings
8
6. EtherNet/IP Settings
This section describes the contents of parameter and tag data link settings that are all defined
in this document.
6.1. Parameters
The parameters required for connecting PLC to Sensor Controller via EtherNet/IP are shown
below.
Item PLC (Node 1) Sensor Controller (Node 50)
IP address 192.168.250.1 192.168.250.50
Subnet mask 255.255.255.0 255.255.255.0
Fieldbus - EtherNet/IP
