7
．
EtherNet/IP Connection Procedure
36
Precautions for Correct Use
Check that the LAN cables are connected before performing the following steps.
If they are not connected, turn OFF each of the devices, and then connect the LAN cables.
3
Select Select Interface - CJ2
USB/Serial Port from the
Option Menu.
4
Select Connect from the
Network Menu.
5
The Setup Interface Dialog Box
is displayed,
Check that the following settings
are made.
Port Type: USB
Port: OMR0
Baud Rate: 115200 Bit/s
Click
OK
.
6
The Select Connect Network
Port Dialog Box is displayed.
Select BackPlane -
CJ2M-EIP21 - TCP:2.
Click OK.
