7
Serial Communications Connection Procedure
28
10
Click Compare in the View
Parameters Dialog Box.
11
Check that a message
"Compare successful" is
displayed in the dialog box on
the right. Click Close.
Click OK in the View
Parameters Dialog Box.
Select Exit from the File Menu
of the PLC IO Table Window to
close.

Other manuals for Omron CJ2M-CPU Series

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Omron CJ2M-CPU Series and is the answer not in the manual?

Omron CJ2M-CPU Series Specifications

General IconGeneral
Power Supply24 VDC
Number of InstructionsOver 400 instructions
ModelCJ2M-CPU11, CJ2M-CPU12, CJ2M-CPU13, CJ2M-CPU14, CJ2M-CPU15
Program Capacity5K steps to 60K steps
I/O CapacityUp to 2, 560 points
Communication PortsEthernet, USB, RS-232C
Execution Time0.04 µs per basic instruction
Operating Temperature0 to 55°C
Position ControlSupported
High-speed Counter100 kHz max.
Pulse Output100 kHz max.
Maximum Units40 units
Storage Temperature-20 to 75°C
Interrupt InputsSupported
