Omron CJ2M-CPU Series Connection Guide

9
．
Program
54
●3.Normal end state management
No. Outline Description
3.1. Normal end
processing
Turns ON the normal end flag if it is detected in 2.3.
Normal/error detection processing that the send/receive
processing ends normally.
3.2. Response code
setting
Sets response code "#0000" for a normal end in the
response code storage area.

Omron CJ2M-CPU Series Specifications

General

Power Supply	24 VDC
Number of Instructions	Over 400 instructions
Model	CJ2M-CPU11, CJ2M-CPU12, CJ2M-CPU13, CJ2M-CPU14, CJ2M-CPU15
Program Capacity	5K steps to 60K steps
I/O Capacity	Up to 2, 560 points
Communication Ports	Ethernet, USB, RS-232C
Execution Time	0.04 µs per basic instruction
Operating Temperature	0 to 55°C
Position Control	Supported
High-speed Counter	100 kHz max.
Pulse Output	100 kHz max.
Maximum Units	40 units
Storage Temperature	-20 to 75°C
Interrupt Inputs	Supported
