Installing Ethernet Networks
The following products are recommended as devices to be used to configure an Ethernet network.
Ethernet Switches
Manufacturer Model Function
Number
of ports
OMRON Corporation W4S1-03B Priority control (QoS): Control data of Ether-
Net/IP is prioritized.
Failure detection: Broadcast storm, LSI er-
ror detection, 10/100BASE-TX, Auto-Nego-
tiation
3
W4S1-05B 5
W4S1-05C
Cisco Systems Inc. Contact the manufacturer.
CONTEC Co., Ltd. Contact the manufacturer.
Phoenix Contact Contact the manufacturer.
Twisted-pair Cables and Connectors
The table below lists 4-pair cables with 24 AWG conductors and connectors for 1000BASE-T/
100BASE-TX.
Product name Manufacturer Model Contact information
Cables Hitachi Metals, Ltd. NETSTAR-C5ESAB 0.5
× 4P
*1
Planning Department,
Kanetsu Co., Ltd.
TEL: 075-662-0996
Kuramo Electric Co., Ltd.
KETH-SB
*1
Kuramo Electric Co., Ltd.
TEL: 03-5644-7601
TEL: 06-6231-8151
SWCC Showa Cable
Systems Co., Ltd.
FAE-5004
*1
SWCC Showa Cable
Systems Co., Ltd.
TEL: 03-5404-6966
RJ45 Connectors Panduit Corporation
MPS588
*1
Panduit Corporation US
Headquarters
Osaka Branch Of
fice
*1. We recommend that you use combinations of the above cables and connectors.
The table below lists 2-pair cables with 22 AWG conductors and connectors for 100BASE-TX.
Product name Manufacturer Model Contact information
Cables Kuramo Electric Co., Ltd.
KETH-PSB-OMR
*1
Kuramo Electric Co., Ltd.
TEL: 03-5644-7601
TEL: 06-6231-8151
SWCC Showa Cable
Systems Co., Ltd.
FAE-5002
*1
SWCC Showa Cable
Systems Co., Ltd.
TEL: 03-5404-6966
JMACS Japan Co., Ltd.
PNET/B
*1
JMACS Japan Co., Ltd.
TEL: 03-3239-5204
TEL: 06-4796-0080
RJ45 Assembly Connec-
tors
OMRON Corporation
XS6G-T421-1
*1
OMRON Customer Serv-
ice Center
TEL: 0120-919-066
*1. We recommend that you use combinations of the above cables and connectors.
5 Wiring
5-13
CK3M-series Programmable Multi-Axis Controller User's Manual Hardware (O036)
5-2 CPU Unit Wiring
5
5-2-2 Laying the Ethernet Network
