71
2-5. Stress Mode
Checking Numerical Values During Stress Test
The [SWITCH VIEW] button can be pressed in the waveform display screen during or after stress
test to switch the screen to "Previous measurement result", "List of results", "ABI - Elapsed time",
or "Waveform screen". Changes in the numerical values being measured can be viewed in these
screens. Select an appropriate screen for the patient and the circumstances.
Previous measurement result screen
Displays graphs of the most recently measured values and pulsatile variation.
1 Interval Counts the standby time until the next measurement.
2 [END STRESS TEST] button Press to stop stress test.
BP-203RPE3(A).fm 71 ページ ９年月６日 土曜日 午後５時４分
